Blank Oiling Unit

Download Data Box:

Technical_Data_-_Blank_Oiling_Unit.pdf

Opens with: Adobe Acrobat

The JIER Blank Oiling Unit is capable of oiling both sides of regular or irregular shaped blanks.

Features:

Self-cleaning nozzles
Individually controlled nozzles
Programmable oil thickness and temperature
Oil mist separator

Diagram:

Click to enlarge
